| Basic Information | ||
| Supported CPU | AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors | |
| Chipset | AMD B850 | |
| BIOS | Flash BIOS Button | |
| Form Factor | ATX 243.84mm x 304.8mm |
|
| Audio | Realtek ALC897 7.1-Channel High Definition Audio |
|
| Expansion Slots | ||
| PCI | 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor) |
|
| M.2 Socket | 3x M.2 | |
| Memory | ||
| Type | DDR5 | |
| Slots | 4 x UDIMM | |
| Supported Memory | max. 256GB, DDR5 Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8200+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1x DisplayPort Support DisplayPort 1.2, maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports |
|
| Display Port (s) | 1x DisplayPort 1.2 | |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 1x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) 1x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear |
|
| LAN Port (s) | 1x Realtek 8126VB 5G LAN | |
| Supported Storage | 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2, supports 2280/2260 devices 4x SATA 6G M2_1 slot Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) |
|
| Audio | 1x Front Audio (JAUD) | |
| Wireless Communication module | Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Others | ||
| Special Features | 4x EZ Debug LED | |
| Warranty Information | ||
| Manufacturing Warranty | 3 Years Warranty | |
The MSI B850 GAMING PLUS WiFi-7 AM5 ATX Motherboard is built for gamers, creators, and PC enthusiasts who want next-generation performance without compromise. Designed around AMD’s latest AM5 platform, this motherboard delivers powerful DDR5 memory support, ultra-fast PCIe 5.0 connectivity, and cutting-edge WiFi 7 networking, making it an ideal foundation for modern high-performance desktop builds.
Powered by the AMD B850 chipset, the MSI B850 GAMING PLUS WiFi-7 motherboard supports AMD Ryzen 9000, 8000, and 7000 series desktop processors on the AM5 socket. This ensures long-term upgrade potential and exceptional processing power for gaming, streaming, content creation, and professional workloads. The integrated Flash BIOS Button allows easy BIOS updates without installing a CPU, making upgrades and system setup more convenient.
This MSI ATX motherboard is optimized for DDR5 memory, supporting up to 256GB across four UDIMM slots in dual-channel mode. With overclocking speeds reaching up to 8200+ MT/s on supported Ryzen 9000 series processors, users can unlock extreme memory bandwidth for demanding applications. Support for AMD EXPO, memory overclocking, and JEDEC profiles ensures both stability and performance, whether you’re gaming competitively or multitasking heavily.
The MSI B850 GAMING PLUS WiFi-7 AM5 motherboard features multiple PCIe x16 slots, including a primary PCIe 5.0 x16 slot driven directly by the CPU for next-gen graphics cards. Additional PCIe 4.0 and PCIe 3.0 slots offer flexible expansion for capture cards, sound cards, and other peripherals. This future-ready design ensures compatibility with upcoming GPUs and high-bandwidth expansion devices.
For storage performance, this MSI gaming motherboard includes three M.2 slots and four SATA 6G ports. The primary M.2 slot supports PCIe 5.0 x4 speeds for blazing-fast NVMe SSDs, while additional M.2 slots support PCIe 4.0 for high-capacity and high-speed storage solutions. This setup delivers faster boot times, reduced load screens, and seamless data transfers for games and creative projects.
Equipped with a pre-installed WiFi 7 wireless module, the MSI B850 GAMING PLUS WiFi-7 motherboard supports tri-band connectivity across 2.4GHz, 5GHz, and 6GHz with speeds up to 5.8Gbps. Features like MU-MIMO, MLO, and 4KQAM ensure ultra-low latency and stable wireless performance. Additionally, the Realtek 5G LAN port provides high-speed wired networking, perfect for competitive gaming and large file transfers.
The onboard Realtek ALC897 audio chipset delivers 7.1-channel high-definition sound for immersive gaming and entertainment experiences. For display output, the motherboard includes a DisplayPort 1.2 connection supporting up to 4K resolution at 60Hz, ideal for productivity setups and media consumption when using integrated graphics.
This MSI ATX motherboard offers extensive cooling support with dedicated CPU fan, pump, and multiple system fan headers, ensuring stable temperatures under heavy workloads. Addressable RGB and RGB LED headers allow for custom lighting effects to match your gaming setup. EZ Debug LEDs provide quick diagnostics during system boot, making troubleshooting easier for both beginners and experienced builders.
When you buy the MSI B850 GAMING PLUS WiFi-7 AM5 ATX Motherboard from Potaka IT, you’re choosing reliability, authenticity, and expert support. Potaka IT offers competitive pricing, genuine MSI products, and dedicated customer service to help you build or upgrade your PC with confidence. Whether you’re assembling a high-end gaming rig or a future-proof workstation, Potaka IT ensures a smooth buying experience and trusted after-sales support. Upgrade your system today with the MSI B850 GAMING PLUS WiFi-7 AM5 ATX Motherboard from Potaka IT and experience next-level performance, connectivity, and reliability built for the future.
The latest price of MSI B850 GAMING PLUS WiFi-7 Motherboard in Bangladesh is 28,700৳. You can buy the MSI B850 GAMING PLUS WiFi-7 Motherboard at best price from our website or visit any of our showrooms.
