| Basic Information | ||
| Supported CPU | Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 |
|
| Chipset | AMD B850 | |
| Form Factor | mATX 243.84mmx243.84mm |
|
| Audio | Realtek ALC897 7.1-Channel High Definition Audio |
|
| Expansion Slots | ||
| PCI | 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot • Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
|
| M.2 Socket | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M2_2 slot • Supports up to PCIe 4.0 x4 • Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4x UDIMM | |
| Supported Memory | Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8200+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1x HDMI Support HDMITM 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI Support HDMITM 2.1, maximum resolution of 4K 60Hz |
|
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
|
| Display Port (s) | 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
|
| USB (s) | 4x USB 2.0 (Front) 3x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) |
|
| LAN Port (s) | Realtek 8126 5G LAN | |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M2_2 slot • Supports up to PCIe 4.0 x4 • Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) |
|
| Audio | 1x Front Audio (JAUD) | |
| Wireless Communication module | Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.9Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| RAID | Supports RAID 0 and RAID 1 for M.2 NVMe storage devices Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices |
|
| Others | ||
| Special Features | 4x EZ Debug LED 1x EZ Memory Detection LED |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years | |
The MSI PRO B850M-A WIFI PZ AM5 mATX Motherboard brings powerful performance and smart connectivity in a compact micro-ATX form factor. Designed for the latest AMD Ryzen 9000, 8000, and 7000 Series desktop processors, this board delivers cutting-edge support for PCIe 5.0, DDR5 RAM, Wi-Fi 7, and lightning-fast storage. Whether you're a serious gamer, content creator, or looking to future-proof your build, this motherboard offers exceptional value and reliability.
Powered by the AMD B850 chipset and supporting the latest AM5 socket, the MSI PRO B850M-A WIFI PZ is ready for the Ryzen 9000 series and backward compatible with Ryzen 8000 and 7000 series. This ensures not only top-tier performance today but also upgrade flexibility for tomorrow. The board intelligently adjusts PCIe speeds based on the installed processor, optimizing your system automatically.
This motherboard supports up to 256GB of DDR5 memory, with overclocking speeds reaching a staggering 8200+ MT/s depending on your processor and memory configuration. With dual-channel support, AMD EXPO™, and non-ECC unbuffered memory compatibility, you get both performance and stability — perfect for gaming, streaming, or heavy multitasking.
Equipped with four PCIe slots, the PCI_E1 slot supports PCIe 5.0 x16, delivering unrivaled bandwidth for next-gen GPUs. Other slots include PCIe 4.0 and 3.0 lanes, offering versatile expansion options for sound cards, capture cards, or additional NVMe storage. Whether you’re building a high-end gaming rig or a professional workstation, this board has the lanes to support your ambitions.
Storage speed matters, and the MSI PRO B850M-A doesn’t disappoint. Featuring two M.2 slots, the primary M.2 supports PCIe 5.0 x4, unleashing ultra-fast NVMe SSD speeds ideal for gaming, boot drives, or editing large media files. The second slot supports PCIe 4.0, still plenty fast for modern workloads. Combined with four SATA 6Gb/s ports, your storage setup is flexible and blazing fast.
With 7.1-channel high-definition audio, powered by the Realtek ALC897 codec, your games, movies, and conference calls will sound incredibly clear. Whether you're using premium headphones or a multi-speaker setup, enjoy immersive and detailed sound without needing a dedicated sound card.
Stay ahead with the latest Wi-Fi 7 technology, built into the board and pre-installed via the M.2 Key-E slot. It supports ultra-fast wireless speeds up to 2.9Gbps, tri-band connections, and MU-MIMO for optimal performance even in crowded networks. For wired reliability, the Realtek 8126 5G LAN port delivers lightning-fast and stable internet for gaming, streaming, or downloading large files.
With 1x HDMI 2.1 and 1x DisplayPort 1.4, the motherboard supports 4K at 60Hz, making it ideal for creators, multi-display users, or anyone looking to leverage integrated graphics. Enjoy crisp visuals right out of the box. Need plenty of USB connectivity? This board offers an abundance — including USB 10Gbps Type-C, USB 5Gbps Type-A, and USB 2.0 ports both front and rear. From peripherals to VR headsets and external drives, this motherboard has the I/O options to keep you connected.
MSI includes 4x EZ Debug LEDs and an EZ Memory Detection LED, making DIY setup and troubleshooting much simpler. This is especially useful when overclocking or building a PC for the first time. Other premium features include TPM 2.0 support for Windows 11 security and robust power delivery via dedicated CPU and PCIe power connectors.
At Potaka IT, we offer genuine products, competitive pricing, and excellent customer service. We understand what PC builders in Bangladesh need reliability, authenticity, and after-sales support. When you buy the MSI PRO B850M-A WIFI PZ from us, you’re not just purchasing a component you’re investing in a future-proof, high-performance build backed by a trusted local tech store. Whether you're upgrading or building from scratch, this motherboard checks all the boxes for speed, stability, and next-gen support. Available now at Potaka IT, your one-stop solution for quality PC hardware.
The latest price of MSI PRO B850M-A WIFI PZ Motherboard in Bangladesh is 29,500৳. You can buy the MSI PRO B850M-A WIFI PZ Motherboard at best price from our website or visit any of our showrooms.
