| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for the 14th, 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with the CPU |
|
| Chipset | Intel B760 Express Chipset | |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
|
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1, PCIEX1_2) |
|
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2M_SB) 4 x SATA 6Gb/s connectors |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 4 | |
| Supported Memory | Support for DDR4 5333(O.C.) / 5133(O.C.) / 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x USB Type-C® header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper |
|
| Display Port (s) | 1x DisplayPort | |
| USB (s) | 1 x USB Type-C port, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) 4 x USB 3.2 Gen 1 port 4 x USB 2.0/1.1 ports |
|
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) 1 x RJ-45 port |
|
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2M_SB) 4 x SATA 6Gb/s connectors |
|
| Audio | 1 x front panel audio header 2 x audio jacks |
|
| VGA (s) | 1x VGA | |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | |
| Others | ||
| Special Features | 2 x addressable LED strip headers 2 x RGB LED strip headers iTE I/O Controller Chip Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
If you're building a high-performance PC in Bangladesh, the GIGABYTE B760 AORUS ELITE DDR4 motherboard is an ideal choice. Designed to support Intel’s 14th, 13th, and 12th Gen processors with the LGA1700 socket, this ATX motherboard delivers superior speed, performance, and durability for gaming and productivity. It combines powerful connectivity options, support for ultra-fast memory, and future-ready features, making it perfect for modern computing needs. With support for DDR4 memory up to 5333 MHz (OC), integrated Intel HD Graphics outputs, and cutting-edge audio, this motherboard caters to every enthusiast's demand while staying compatible with older generation CPUs.
Supports Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors using the latest LGA1700 socket, ensuring performance scalability and futureproofing.
Features four DDR4 DIMM slots with dual-channel architecture and XMP profile support, allowing up to 128GB of high-speed memory overclockable to 5333 MHz.
Equipped with three PCIe 4.0 M.2 slots and four SATA ports for high-speed storage performance, fast boot times, and improved game loading speeds.
Offers a variety of USB ports including USB 3.2 Gen 2 Type-C and Type-A, along with HDMI and DisplayPort for versatile display output and peripheral compatibility.
Integrated Realtek High Definition Audio supports up to 7.1-channel sound with S/PDIF out, enhancing your multimedia and gaming experience.
Built-in Realtek 2.5GbE LAN for ultra-fast and stable wired internet connection, ideal for streaming, gaming, and heavy data transfers.
Comes with two addressable and two RGB LED strip headers, offering customizable lighting options for a visually stunning PC build.
Fully compatible with GIGABYTE Control Center (GCC) for centralized software management, BIOS updates, and system tuning.
Built with a 30.5cm x 24.4cm ATX form factor, this motherboard fits most standard cases and provides a solid foundation for any build.
Allows BIOS updates without a CPU or memory, making setup and troubleshooting quicker and easier for both beginners and experts.
Looking to upgrade your PC with a powerful and feature-rich motherboard in Bangladesh? Buy the GIGABYTE B760 AORUS ELITE DDR4 from Potaka IT today and experience unmatched quality and performance. At Potaka IT, we offer authentic products with a 3-year official warranty, competitive prices, and expert customer service. Whether you're a gamer, creator, or tech enthusiast, this motherboard is the perfect match for your high-end build. Order now from Potaka IT for fast delivery and reliable after-sales support across BD.
The latest price of GIGABYTE B760 AORUS ELITE Motherboard in Bangladesh is 23,900৳. You can buy the GIGABYTE B760 AORUS ELITE Motherboard at best price from our website or visit any of our showrooms.
