Gigabyte Z890 UD DDR5 intel Motherboard

Name: Gigabyte Z890 UD DDR5 intel Motherboard
Brand: Gigabyte
SKU: 894521
Price: 31000 BDT
Availability: InStock

Price:

31,000৳ 33,000৳

Stock :

In Stock

Model :

Z890 UD

SKU :

894521

Brand :

Gigabyte

31,000৳ 33,000৳

Offer Price End In

Days

Hours

Minutes

Seconds

Key Features

Supported CPU: Intel Core Ultra Processors (Series 2), LGA1851 socket
Supported RAM: 4x DDR5, Max 256GB, Supports Up to 9200 (O.C)
Graphics Output: 1x USB4 USB Type-C, 1x DisplayPort
Features: 3x M.2 slots, Wi-Fi 6E, Bluetooth 5.3

Specification
Description
Reviews
Questions

Basic Information
Supported CPU	LGA1851 socket: Support for Intel Core Ultra Processors L3 cache varies with CPU
Chipset	Intel Z890 Express Chipset
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
Expansion Slots
PCI	CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: - 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)
M.2 Socket	CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
Memory
Type	DDR5
Slots	4 x DIMM
Supported Memory	Support for DDR5 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules. Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Support CUDIMM memory module
Maximum Memory	up to 256 GB (64 GB single DIMM capacity) of system memory
Graphics
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: - 1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 2.1 version - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 2.1 version
Connector & Ports
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x power button 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper 4 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 1 x DisplayPort (Note) 4 x USB 3.2 Gen 1 ports 1 x USB4® USB Type-C® port (DisplayPort (Note)) 1 x USB 3.2 Gen 2 Type-A port (red) 1 x RJ-45 port 2 x SMA antenna connectors (2T2R) 3 x audio jacks
Display Port (s)	1 x DisplayPort
LAN Port (s)	Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0x4/x2 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors
Audio	3 x audio jacks
Wireless Communication module	Intel® Wi-Fi 6E AX211 (PCB rev. 1.0) - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.1) - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 160MHz wireless standard (Actual data rate may vary depending on environment and equipment.)
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only)
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Others
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Warranty Information
Manufacturing Warranty	3 Year

Description

Gigabyte Z890 UD DDR5 Intel Motherboard

The Gigabyte Z890 UD DDR5 Intel Motherboard is designed for gamers, creators, and tech enthusiasts who demand high performance and reliability. Compatible with Intel Core Ultra Processors (Series 2) via the LGA1851 socket, this ATX motherboard ensures smooth computing, multitasking, and gaming experiences. Equipped with the latest DDR5 memory support and advanced graphics outputs, the Z890 UD is a perfect foundation for building a cutting-edge PC.

High-Performance CPU Support

With support for Intel Core Ultra Processors and LGA1851 socket, the Gigabyte Z890 UD delivers top-tier processing power. The motherboard features an Intel Z890 Express Chipset and AMI UEFI BIOS, ensuring seamless compatibility, stability, and overclocking potential for demanding applications.

DDR5 Memory Support

Featuring 4 DDR5 DIMM slots, the motherboard supports up to 256GB of RAM and speeds up to 9200(O.C). Dual-channel memory architecture, Extreme Memory Profile (XMP), and ECC/Non-ECC support make it ideal for gaming, content creation, and professional workloads.

Advanced Graphics Outputs

The integrated Intel HD Graphics support provides multiple display options with 1 x USB4 Type-C port and 1 x DisplayPort, both capable of delivering 4K resolution at 144Hz. DisplayPort 2.1 support ensures superior video performance for modern monitors and multi-display setups.

Robust Storage Options

The motherboard includes 3 x M.2 slots and 4 x SATA 6Gb/s ports, supporting PCIe 5.0/4.0 and SATA SSDs for ultra-fast storage. RAID 0, 1, 5, and 10 configurations are also supported, giving users flexibility and speed for storage-intensive tasks.

Connectivity and Expansion

Equipped with multiple expansion slots, including PCIe 5.0 x16 for graphics cards and PCIe 4.0 x4 slots, this motherboard provides versatility for adding GPUs or NVMe SSDs. Internal connectors include USB 3.2, USB 2.0, Type-C headers, Thunderbolt add-in card connectors, RGB headers, and fan headers for a fully customizable setup.

Wireless and Networking

Featuring Intel Wi-Fi 6E AX211 and Realtek Wi-Fi 6E RTL8852CE modules with Bluetooth 5.3 support, this motherboard ensures ultra-fast wireless connectivity. The Realtek 2.5GbE LAN chip provides reliable and high-speed wired networking for gaming and professional use.

Audio and Multimedia

High-definition Realtek Audio CODEC supports 2/4/5.1/7.1 channel audio output, ensuring immersive sound for gaming, streaming, and media playback. This makes the motherboard suitable for entertainment, work, and content creation environments.

Special Features

Support for GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, and Smart Backup software provides users with tools to easily manage performance, BIOS updates, and data protection. These features enhance the overall user experience and system reliability.

Why You Can Buy From Potaka IT

Potaka IT brings you authentic Gigabyte motherboards with fast delivery across Bangladesh. Enjoy the best prices, verified products, and dedicated customer support when shopping with us. Build your ultimate PC setup confidently with Potaka IT’s trusted service.

What is the price of Gigabyte Z890 UD Motherboard in Bangladesh?

The latest price of Gigabyte Z890 UD Motherboard in Bangladesh is 31,000৳. You can buy the Gigabyte Z890 UD Motherboard at best price from our website or visit any of our showrooms.
