| General | ||
| Brand | Hikvision | |
| Model | Hikvision Cat-6 U/UTP | |
| Type | Network Cable | |
| Part No | DS-1LN6UZC0 | |
| Technical Info | ||
| Length | 1 Meter | |
| Connector Type | RJ45 | |
| Product Type | Round Cable | |
| Main Features | ||
| Conductor Material | Solid-Bare Copper | |
| Jacket Material | PVC | |
| Cable Shielding | U/UTP | |
| AWG | 24AWG | |
| Additional Info | ||
| Color | Blue | |
| Others | Reference standard: ISO/IEC11801, ANSI/TIA-568.2-D, RoHS 2.0. Conductor Diameter: 0.50 ± 0.01 mm. Insulation Material: HDPE. Insulation Diameter: 0.88 ± 0.05 mm. Sheath Thickness: 0.50 ± 0.05 mm. Sheath Diameter: 5.30 ± 0.50 mm. Rip-cord: Yes. Separator: Yes. Impedance: 100 ± 15Ω (1.0–250.0 MHz). Delay Skew: ≤45 ns/100m. DC Resistance: ≤9.38Ω/100m. Operating Voltage: 57V. Ambient Temperature: -20°C to 70°C. | |
| Feature | Stable electrical performance compliant with ANSI/TIA-568.2-D, IEC61156, and ISO/IEC11801. RoHS 2.0 compliant. High-strength sheath with excellent tensile and compressive resistance. Passes Fluke 90m permanent link testing at 50°C and Fluke 100m channel testing under 57V/1A PoE load. Solid-Bare Copper conductor provides lower resistance and improved transmission performance. | |
| Warranty | ||
| Warranty | No Warranty | |
The Hikvision Cat-6 U/UTP 1 Meter Network Cable is a reliable high-performance networking solution designed for stable data transmission in homes, offices, surveillance systems, and commercial environments. Built with a 24AWG solid-bare copper conductor and high-quality RJ45 connectors, this Cat6 cable helps ensure consistent network connectivity for computers, routers, switches, IP cameras, and other network devices. Available from Potaka IT, this cable is an excellent choice for users looking for dependable network performance in Bangladesh.
Whether you are connecting a desktop workstation, network switch, IP camera, NAS device, or other PC Component equipment, the Hikvision Cat-6 U/UTP cable delivers stable communication with reduced signal loss. It is also a practical companion for modern Desktop setups that require dependable wired networking.
| Name | Details |
|---|---|
| Brand | Hikvision |
| Model | Hikvision Cat-6 U/UTP |
| Part Number | DS-1LN6UZC0 |
| Type | Network Cable |
| Length | 1 Meter |
| Connector Type | RJ45 |
| Product Type | Round Cable |
| Conductor Material | Solid-Bare Copper |
| Cable Shielding | U/UTP |
| AWG | 24AWG |
| Color | Blue |
| Warranty | No Warranty |
The Hikvision Cat-6 U/UTP cable is engineered to support stable network communication for modern Ethernet applications. Its solid-bare copper conductor provides lower resistance and improved signal integrity compared to lower-grade cable materials. This results in better data transmission performance for internet access, file transfers, IP surveillance, and local network communications.
The cable complies with internationally recognized standards including ANSI/TIA-568.2-D, IEC61156, and ISO/IEC11801, ensuring dependable performance across a wide range of networking environments.
One of the most important factors in network cable performance is conductor quality. The Hikvision Cat-6 U/UTP cable uses a solid-bare copper conductor that helps maintain signal strength and reduces electrical resistance. This design improves transmission efficiency while supporting long-term network stability.
For businesses, surveillance deployments, and home users, solid copper construction can contribute to more consistent network performance and fewer connectivity issues over time.
This Hikvision network cable demonstrates excellent performance during Fluke channel testing under continuous PoE loads. It can support Power over Ethernet applications where both power and data travel through a single Ethernet cable, making it suitable for IP cameras, access control devices, VoIP phones, and network infrastructure equipment.
Users building surveillance systems can pair this cable with networking hardware and a compatible SSD-based recording system to create a reliable security setup.
The cable features a durable PVC sheath, HDPE insulation, rip-cord design, and separator structure that help improve mechanical strength. Its high tensile and compressive resistance helps reduce damage during installation projects and daily use.
The cable is also designed to operate in ambient temperatures ranging from -20°C to 70°C, making it suitable for a variety of indoor networking environments.
This 1-meter Cat6 cable is suitable for a wide range of networking requirements:
Users building a complete workstation may also explore compatible Monitor options and networking accessories for a more productive setup.
If you need a short Ethernet cable for connecting networking devices over a one-meter distance, this Hikvision Cat-6 U/UTP cable is a practical solution. It is particularly suitable for users who prioritize stable wired networking over wireless connectivity and require dependable signal transmission for work, streaming, gaming, or security systems.
Compared with lower-category Ethernet cables, Cat6 cabling offers improved performance characteristics and is widely used in modern networking infrastructure. Its solid copper construction further enhances reliability, making it a strong choice for both personal and professional environments.
The cable length is 1 meter, making it ideal for short-distance device-to-device network connections.
Yes. The Hikvision Cat-6 U/UTP cable uses a solid-bare copper conductor for improved electrical performance and lower resistance.
Yes. It is suitable for IP camera installations and supports PoE-related applications where compatible devices are used.
The cable comes with RJ45 connectors, which are standard for Ethernet networking equipment.
Yes. It complies with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801, and RoHS 2.0 standards.
Absolutely. It is designed for home users, office networks, surveillance systems, and commercial networking deployments.
The latest price of Hikvision Cat-6 U/UTP, 1 Meter, Blue Network Cable in Bangladesh is 65৳. You can buy the Hikvision Cat-6 U/UTP, 1 Meter, Blue Network Cable at best price from our website or visit any of our showrooms.
