MSI MAG B850M GAMING PRO MAX WIFI AM5 M-ATX Motherboard

Price:

26,500৳

Stock :

In Stock

Model :

MAG B850M GAMING PRO MAX WIFI

SKU :

Brand :

MSI

26,500৳

Key Features

Model: MAG B850M GAMING PRO MAX WIFI
Supported CPU: Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset: AMD B850, Form Factor: mATX
Audio: Realtek® ALC897 7.1-Channel High Definition Audio
Memory: 4x DDR5 UDIMM, Maximum Memory Capacity 256GB

Specification
Description
Reviews
Questions

Basic Information
Supported CPU	Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset	AMD B850
Form Factor	mATX
Audio	Realtek® ALC897 7.1-Channel High Definition Audio
Expansion Slots
PCI	2x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot • Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
M.2 Socket	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280/2260 devices 4x SATA 6G M2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M2_2 slot • Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 8700/ 8600/ 8400/ 7000 Series processors) • Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
Memory
Type	DDR5
Supported Memory	Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8200+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only*
Maximum Memory	Maximum Memory Capacity 256GB
Graphics
Graphics	1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz*
Connector & Ports
Internal I/O Ports	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 2x Direct OC Jumper (JBCLK) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
USB (s)	4x USB 2.0 (Front) 3x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front)
LAN Port (s)	Realtek® 8126 5G LAN
Wireless Communication module	Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.9Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4**, MLO, 4KQAM
RAID	Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Others
Special Features	Support for Windows® 11 64-bit

Description

MSI MAG B850M GAMING PRO MAX WIFI AM5 M-ATX Motherboard

The MSI MAG B850M GAMING PRO MAX WIFI AM5 M-ATX Motherboard is a powerful next-generation motherboard designed for AMD Ryzen 9000, 8000, and 7000 Series processors. Built on the AMD B850 chipset, it combines PCIe 5.0 support, ultra-fast DDR5 memory, Wi-Fi 7 connectivity, and advanced storage options to deliver exceptional gaming, productivity, and content creation performance. Its Micro-ATX form factor makes it an excellent choice for compact yet powerful PC builds.

Built for AMD Ryzen 9000, 8000, and 7000 Series Processors

Featuring the latest AM5 socket and AMD B850 chipset, this MSI gaming motherboard is optimized for modern Ryzen processors. It provides excellent system stability, efficient power delivery, and future-ready platform support, making it ideal for gamers, streamers, and professional creators.

Extreme DDR5 Memory Performance

The MSI MAG B850M GAMING PRO MAX WIFI supports DDR5 memory up to 8200+ MT/s (OC), delivering exceptional speed and responsiveness. With support for up to 256GB of dual-channel DDR5 memory and AMD EXPO technology, users can unlock enhanced gaming performance, faster multitasking, and smoother workflow experiences.

PCIe 5.0 Graphics and Advanced Expansion

The motherboard features a PCIe 5.0 x16 slot for next-generation graphics cards, ensuring maximum bandwidth for high-end gaming and professional workloads. A secondary PCIe 4.0 x16 slot provides additional expansion flexibility for capture cards, storage controllers, and other peripherals.

Ultra-Fast Storage with Triple M.2 Slots

Equipped with three M.2 slots and four SATA 6Gb/s ports, the motherboard offers extensive storage options. The primary M.2 slot supports PCIe 5.0 x4 NVMe SSDs for blazing-fast data transfer speeds, while additional PCIe 4.0 M.2 slots provide flexible storage expansion. RAID support for both SATA and NVMe drives enhances performance and data management capabilities.

Wi-Fi 7 and 5G LAN Connectivity

Stay connected with cutting-edge Wi-Fi 7 technology, supporting speeds up to 2.9Gbps across 2.4GHz, 5GHz, and 6GHz bands. The integrated Bluetooth 5.4 and Realtek 8126 5G LAN controller deliver ultra-fast networking, low latency, and reliable connections for competitive gaming, streaming, and professional networking tasks.

4K Display Support and Premium Audio

The motherboard includes HDMI 2.1 and DisplayPort 1.4 outputs, supporting up to 4K resolution at 60Hz with compatible Ryzen processors featuring integrated graphics. The Realtek ALC897 7.1-channel High Definition Audio system provides immersive sound quality for gaming, entertainment, and multimedia applications.

Comprehensive Connectivity and RGB Customization

With multiple USB 10Gbps Type-C and Type-A ports, extensive fan headers, TPM 2.0 support, RGB lighting connectors, and advanced cooling controls, this motherboard offers everything needed to build a modern, high-performance gaming PC. Support for Windows 11 ensures full compatibility with the latest software and gaming technologies.

Why Buy the MSI MAG B850M GAMING PRO MAX WIFI Motherboard from Potaka IT?

Potaka IT offers genuine MSI motherboards at competitive prices in Bangladesh. When you purchase the MSI MAG B850M GAMING PRO MAX WIFI AM5 M-ATX Motherboard from Potaka IT, you receive an authentic product, manufacturer-backed warranty support, expert customer service, and dependable after-sales assistance. Potaka IT is your trusted destination for gaming hardware, PC components, and next-generation AMD motherboard solutions.

What is the price of MSI MAG B850M GAMING PRO MAX WIFI Motherboard in Bangladesh?

The latest price of MSI MAG B850M GAMING PRO MAX WIFI Motherboard in Bangladesh is 26,500৳. You can buy the MSI MAG B850M GAMING PRO MAX WIFI Motherboard at best price from our website or visit any of our showrooms.
