Thermaltake Smart BX1 550W 80 Plus RGB Bronze Non-Modular Power Supply

• 10 RGB LED FAN - 120mm 10 RGB LED Fan displaying 7 colors (Red Green Blue Yellow Purple Light Blue White) with 3 illumination modes (Pulse Full-Lighted RGB Cycle)

• ONE BUTTON RGB CONTROL - RGB Lighting Button controls lighting effects Total 16 modes
• 16 LIGHTING MODES - Pulse mode (7 colors) Full-Lighted (7 colors) RGB Cycle and LED Off
• 80+ BRONZE - Efficiency up to 85% and optimized for C6/C7 States Ready
• ULTRA QUITE - 120mm hydraulic bearing fan superior cooling performance and silent operation
• 24 Pin x 1 ATX 12V 4+4 Pin x 1 SATA 4 Pin x 6 PCI-E 6+2 Pin x 2 Peripheral x 4 FDD Adapter x 1
• MAIN JAPANESE CAPACITORS - 105°C/221°F Japanese capacitors provide superb performance and reliability
• INDUSTRIAL PROTECTIONS - (OPP) Over Power (OVP) Over Voltage and (SCP) Short-Circuit protections
• SINGLE +12V RAIL DESIG - Powerful 12V+ single rail supports today’s GPU demands supporting DC to DC design for stable reliable power

One Button RGB Control

RGB Lighting Button at the back of PSU controls 16 different modes

1. Mode 1-7: Solid Red, Solid Green, Solid Blue, Solid Yellow, Solid Purple, Solid Light Blue, Solid White

2. Mode 8-14: Pulse Red, Pulse Green, Pulse Blue, Pulse Yellow, Pulse Purple, Pulse Light Blue, Pulse White

3. Mode 15: RGB Cycle

4. Mode 16: LED Off

Ultra Quiet 120mm Hydraulic Bearing RGB Fan

120mm Hydraulic Bearing Fan with intelligent RPM control guarantees superior cooling performance and silent operation.

80+ Bronze / C6 C7 States Ready

Efficiency up to 85% certified to 80 PLUS Bronze, Smart BX1 RGB series has been optimized to work with all Intel processors to achieve maximum energy saving.

High Quality Japanese Main Capacitor

Greatly improves the durability and offers the highest stability and reliability.

Thermaltake Smart BX1 is Built to deliver 80 PLUS Bronze efficiency, Smart BX1 RGB series is available in 550W, 650W, and 750W models. The preinstalled 10 LED RGB fan provides excellent airflow, and also 3 lighting modes, 7 color options, LED Off, and a built-in memory function, which saves the colors applied and insure the same color selection every time you boot your PC. Comes with premium components, stable continuous power output at 40℃, and ample 5-year , its near silent operation, trouble free installation and reliable performance have made itself satisfy the market where value-oriented users are looking for a power supply with advanced features and aesthetic appeal. Type: ATX 12V v2. 4 and EPS v2. 92 Max. Output Capacity: 550W Peak Output Capacity: 660W Color: Black Dimension: 150mm (W) x 86mm (H) x 140mm (D) PFC (Power Factor Correction): Active PFC Power Good Signal: 100-500 msec Hold Up Time: > 16msec at 70% of full load Input Current: 10A max Input Frequency Range: 50Hz - 60Hz Input Voltage: 100V – 240V~ Operating Temperature : 5°C to + 40°C Operating Humidity: 20% to 85%, non-condensing Storage Temperature: -40°C to + 55°C Storage Humidity: 10% to 95%, non-condensing Cooling System: 12cm Fan Hub Efficiency: Meet 80 PLUS Bronze at 115Vac input MTBF: 100, 000 hrs minimum Safety Approval : CE/CB/TUV/ UL/ FCC/ BSMI Protection: OVP, OPP, SCP Connectors Main Power Connector (24 Pin) x 1: 600mm ATX 12V (4+4 Pin) x 1: 650mm SATA (4 Pin) x 6: 500mm+150mm+150mm / 500mm+150mm+150mm PCI-E (6+2 Pin) x 2: 500mm+150mm Peripheral (4 Pin) x 4: 500mm+150mm+150mm+150mm FDD Adapter (4 Pin) x 1
