| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for the 14th, 14th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with the CPU |
|
| Chipset | Intel B760 Express Chipset | |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
|
| Expansion Slots | ||
| PCI | CPU: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 2 | |
| Supported Memory | Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | up to 64GB (32 GB single DIMM capacity) of system memory | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper |
|
| USB (s) | Chipset: - 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) - 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
|
| LAN Port (s) | Realtek GbE LAN chip (1 Gbps/100 Mbps) | |
| Supported Storage | CPU: - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) - 4 x SATA 6Gb/s connectors |
|
| Audio | 3 x audio jacks | |
| D-Sub (s) | 1x D-Sub | |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| RAID | RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices | |
| Others | ||
| Special Features | Support for GIGABYTE Control Center (GCC) Support for Q-Flash |
|
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
The GIGABYTE B760M H DDR4 mATX motherboard is designed for high-performance PC builds using 12th, 13th, or 14th Gen Intel processors. Featuring LGA1700 socket support, DDR4 memory up to 64GB, and PCIe 4.0, this motherboard is ideal for gamers, content creators, and professional users in Bangladesh who want fast and stable computing.
This motherboard supports Intel’s latest 14th, 13th, and 12th generation Core, Pentium Gold, and Celeron processors. With the LGA1700 socket and Intel B760 Express Chipset, you can build a future-proof system for both performance and efficiency.
Equipped with two DDR4 slots, this motherboard can handle up to 64GB of RAM running at 3200 MHz. It supports both ECC and non-ECC un-buffered DIMMs, making it flexible for both gaming and workstation setups.
Enjoy faster boot times and load speeds with dual M.2 PCIe 4.0 slots supporting SSDs, along with 4 x SATA 6Gb/s connectors for traditional HDD/SSD support. RAID 0, 1, 5, and 10 are available for data protection and performance.
The integrated Intel HD Graphics supports 1x HDMI (4K@60Hz) and 1x D-Sub (1080p@60Hz) output, making it suitable for dual-display setups. Perfect for office work, media consumption, and light gaming.
Comes with Realtek GbE LAN chip providing stable 1Gbps wired internet. For connectivity, it includes 6 x USB 3.2 Gen 1 ports and 6 x USB 2.0/1.1 ports, giving you plenty of expansion options for peripherals and accessories.
Enjoy crisp and immersive audio with the Realtek High Definition Audio CODEC supporting up to 7.1-channel sound. Audio jacks can be customized using bundled software for personalized audio experiences.
With a size of 23.0cm x 21.5cm, the B760M H fits perfectly in most mid and mini-tower cases. Ideal for users looking to save space without compromising features.
Includes RGB header, TPM header, support for Q-Flash BIOS updates, and bundled software like Norton Internet Security and LAN bandwidth management. Comes with robust BIOS features for system stability.
Potaka IT is your trusted tech partner in Bangladesh, offering genuine GIGABYTE motherboards at competitive prices. We ensure fast delivery, professional customer support, and easy return policies. Buy from Potaka IT and enjoy peace of mind with every purchase.
The latest price of GIGABYTE B760M H DDR4 mATX Motherboard in Bangladesh is 13,700৳. You can buy the GIGABYTE B760M H DDR4 mATX Motherboard at best price from our website or visit any of our showrooms.
