| Basic Information | ||
| Supported CPU | Support Intel Core Ultra Processors (Series 2), LGA1851 Supports Intel Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 |
|
| Chipset | Intel Z890 Chipset |
|
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
|
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
|
| Audio | Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback*Audio Features - Gold-plated audio jacks - Premium audio capacitors - Dedicated audio PCB layers * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. |
|
| Expansion Slots | ||
| PCI | Intel Core Ultra Processors (Series 2) 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes) Intel Z890 Chipset *1 x PCIe 4.0 x16 slot (supports x4 mode) |
|
| M.2 Socket | Total supports 5 x M.2 slots Intel Core Ultra Processors (Series 2) M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel® Z890 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes) M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4 x DIMM slots |
|
| Supported Memory | Support up to 9066+MT/s (OC), Non-ECC, Un-buffered and Clocked Unbuffered DIMM (CUDIMM) Dual channel memory architecture Supports Intel® Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III (AEMP III) Support DIMM Fit Support DIMM Flex |
|
| Maximum Memory | 256GB |
|
| Graphics | ||
| Graphics | 1 x HDMI™ port** 2 x Intel® Thunderbolt™ 5 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs*** 1 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs**** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. ** Supports 4K@60Hz as specified in HDMI 2.1 *** Supports up to 2 x 8K@60HZ (DSC mode) + 1 x 4K@60HZ monitors with DP in. *** Supports up to 1 x 8K@60HZ (DSC mode) + 1 x 4K@60HZ monitors without DP in. *** For resolution support please check DisplayPort 2.1 specs. ThunderboltTM 5 bandwidth is limited by DisplayPort™ 2.1 with up to 77.4 Gbit/s. We recommend chain-connecting the monitors using verified Thunderbolt cables. In ThunderboltTM 4 mode, supports up to 8K@60Hz x1 with DSC, maximum total bandwidth up to 23.8Gbps, for resolution support please check DisplayPort 2.1 specs. In DP alt mode, supports up to UHBR20. While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card. |
|
| Max Shared Memory | ||
| Connector & Ports | ||
| HDMI | 1 x HDMI | |
| Internal I/O Ports | Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 2 x 8-pin +12V CPU Power connector Storage Related 5 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 20Gbps connector (supports USB Type-C® ) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen2 headers 1 x Clear CMOS button 1 x COM Port header 1 x CPU Over voltage jumper 1 x Chassis Intrusion header 1 x Front Panel Audio header (F_AUDIO) 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin Front System Panel header 1 x Thermal Sensor header |
|
| Display Port (s) | 2 x Intel Thunderbolt 5 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs 1 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs |
|
| USB (s) | Rear USB (Total 10 ports) 2 x Thunderbolt™ 5 ports (2 x USB Type-C®) 1 x Thunderbolt™ 4 port (1 x USB Type-C®) 6 x USB 10Gbps ports (6 x Type-A ) 1 x USB 2.0 port (1 x Type-A ) Front USB (Total 5 ports) 1 x USB 20Gbps (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports USB Type-C® power delivery output: max. 5V/3A |
|
| LAN Port (s) | 1 x Marvell AQtion 10Gb Ethernet 1 x Intel 2.5Gb Ethernet ASUS LANGuard |
|
| Supported Storage | Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports* Intel® Core™ Ultra Processors (Series 2) * M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel® Z890 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes) M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)** 4 x SATA 6Gb/s ports * Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5. ** M.2_5 slot shares bandwidth with PCIe 4.0 x16 slot. When M.2_5 slot is operating, PCIe 4.0 x16 slot will be disabled. |
|
| Audio | 2 x Gold-plated audio jacks | |
| D-Sub (s) | ||
| DVI-D (s) | ||
| Wireless Communication module | Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate. Bluetooth® v5.4*** *Wi-Fi features may vary depending on the operating system For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E. For Windows 10, only Wi-Fi 6 is supported. ** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries. *** The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications. |
|
| VGA (s) | ||
| TPM (Trusted Platform Module ) | ||
| RAID | Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5. | |
| Others | ||
| Special Features | ASUS 5X PROTECTION III / - DIGI+ VRM (- Digital power design with DrMOS) - ESD Guards - LANGuard - Overvoltage protection - SafeSlot - Stainless-steel back I/O ASUS Q-Design - M.2 Q-Latch - M.2 Q-Release - M.2 Q-Slide - Q-Release Slim (with PCIe SafeSlot) - Q-Antenna - Q-Connector - Q-Dashboard - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Box headers - Clear CMOS button - CPU Socket lever protector - ProCool II - Pre-mounted I/O shield - SafeDIMM Aura Sync - Addressable Gen2 headers Bespoke Motherboard Design & Business Focused Features - 24/7 reliability- Overcurrent protection |
|
| Bundled Software | ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 - Power Saving ASUS Driver Hub ASUS GlideX ASUS CPU-Z CreatonFirst ProArt Creator Hub TurboV Core Thunderbolt™ Share USB Wattage Watcher Adobe Creative Cloud (Free Trial) Norton 360 Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS AI Overclocking Guide ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey NPU Boost |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years | |
The ASUS ProArt Z890-CREATOR WIFI LGA1851 ATX Motherboard is a premium Intel Z890 motherboard designed for professional creators, video editors, designers, developers, and users building powerful desktop workstations. Supporting Intel Core Ultra Processors (Series 2), DDR5 memory up to 256GB, PCIe 5.0 expansion, and five M.2 storage slots, it provides a flexible foundation for demanding creative workloads. Its standout connectivity includes dual Thunderbolt 5 ports, one Thunderbolt 4 port, 10Gb Ethernet, 2.5Gb Ethernet, Wi-Fi 7, and Bluetooth 5.4.
Whether you are building a professional video-editing PC, a 3D rendering workstation, or a high-performance development system, this ASUS ProArt motherboard combines fast data connectivity, extensive storage expansion, and reliable power delivery. If you are comparing premium motherboards or planning a complete workstation with compatible processors, this model deserves consideration. Check the latest ASUS ProArt Z890-CREATOR WIFI price in Bangladesh at Potaka IT.
This ATX motherboard supports Intel Core Ultra Processors (Series 2) using the LGA1851 socket. The Intel Z890 chipset, advanced power delivery, and support for Intel Turbo Boost technologies provide a capable platform for demanding professional applications. Before purchasing, verify your processor's compatibility and ensure that your selected CPU, memory, and cooling solution meet your workstation requirements.
Four DDR5 DIMM slots support up to 256GB of memory, with supported overclocked memory speeds reaching 9066+ MT/s under suitable configurations. Dual-channel memory architecture, Intel XMP, ASUS Enhanced Memory Profile III (AEMP III), DIMM Fit, and DIMM Flex provide additional memory configuration options. This capacity is useful for large creative projects, multitasking, software development, and memory-intensive professional applications. Actual supported speeds depend on the processor, memory kit, and system configuration.
One of the major advantages of the ASUS ProArt Z890-CREATOR WIFI is its versatile high-speed connectivity. It features two Thunderbolt 5 USB Type-C ports and one Thunderbolt 4 USB Type-C port, supporting compatible high-bandwidth peripherals and display connections. Thunderbolt 5 can deliver up to 80Gbps of bidirectional bandwidth, with Bandwidth Boost reaching up to 120Gbps under supported conditions.
The motherboard also includes an HDMI 2.1 output supporting up to 4K at 60Hz. Thunderbolt display capabilities depend on the connection method, compatible devices, and graphics configuration. For certain Thunderbolt display setups, a discrete graphics card must be connected to the motherboard's DisplayPort input.
Storage flexibility is another important advantage. The motherboard includes five M.2 slots: one PCIe 5.0 x4 slot and four PCIe 4.0-capable slots, including one that also supports SATA-mode M.2 drives. Four SATA 6Gb/s ports provide additional storage options. This configuration allows users to build systems with multiple SSDs for operating systems, active projects, application libraries, and large media files.
Two PCIe 5.0 x16 slots support x16 operation or an x8/x8 configuration, while an additional PCIe 4.0 x16 slot operates at up to x4 mode. Please note that using the fifth M.2 slot disables the PCIe 4.0 x16 slot because they share bandwidth.
The ASUS ProArt Z890-CREATOR WIFI provides one 10Gb Ethernet port and one 2.5Gb Ethernet port for high-speed wired networking. These connections can benefit creative studios transferring large video files, professionals accessing network-attached storage, and teams working with shared project resources. Wi-Fi 7 and Bluetooth 5.4 offer additional wireless connectivity, subject to compatible devices, operating systems, and regional availability.
Its 16+1+2+2 power-stage design supports demanding compatible Intel processors. Dedicated VRM and M.2 heatsinks help manage heat, while multiple fan headers allow flexible cooling configurations. ASUS ProCool II power connectors, SafeSlot reinforcement, and protection features contribute to a carefully designed workstation platform.
The Realtek ALC1220P audio codec supports 7.1-channel high-definition audio and up to 32-bit/192kHz playback under supported configurations. Gold-plated audio jacks and dedicated audio PCB layers contribute to the audio design. ASUS Q-Design features, including M.2 Q-Latch, M.2 Q-Release, Q-Antenna, Q-LED, and BIOS FlashBack, simplify selected installation, troubleshooting, and maintenance tasks.
For a complete workstation, explore compatible desktop RAM and SSD storage options. Select components according to the motherboard's compatibility requirements and your intended workload.
| Name | Details |
|---|---|
| Brand | ASUS |
| Model | ProArt Z890-CREATOR WIFI |
| Motherboard Chipset | Intel Z890 |
| Supported Processor | Intel Core Ultra Processors (Series 2) |
| CPU Socket | LGA1851 |
| Form Factor | ATX |
| Dimensions | 12 × 9.6 inches (30.5 × 24.4 cm) |
| Memory Type | DDR5 |
| Memory Slots | 4 × DIMM |
| Maximum Memory | 256GB |
| Maximum Memory Speed | 9066+ MT/s (OC, configuration-dependent) |
| PCIe Expansion | 2 × PCIe 5.0 x16 slots; 1 × PCIe 4.0 x16 slot operating at up to x4 |
| M.2 Slots | 5 total: 1 × PCIe 5.0 x4 and 4 × PCIe 4.0-capable slots |
| SATA Ports | 4 × SATA 6Gb/s |
| Graphics Output | 1 × HDMI 2.1; 2 × Thunderbolt 5 Type-C; 1 × Thunderbolt 4 Type-C |
| USB Connectivity | Rear: 2 × Thunderbolt 5 Type-C, 1 × Thunderbolt 4 Type-C, 6 × USB 10Gbps Type-A, 1 × USB 2.0 Type-A; front-panel headers provide additional connectivity |
| Ethernet | 1 × 10Gb Ethernet; 1 × 2.5Gb Ethernet |
| Wireless | Wi-Fi 7 |
| Bluetooth | Bluetooth 5.4 |
| Audio | Realtek ALC1220P 7.1-channel HD Audio |
| BIOS | 256Mb Flash ROM, UEFI AMI BIOS |
| Cooling Support | CPU fan, CPU optional fan, AIO pump, and 5 chassis fan headers |
| Special Features | ASUS Q-Design, SafeSlot, BIOS FlashBack, Aura Sync, ProArt Creator Hub |
| Warranty | 3 years manufacturing warranty, subject to local warranty terms |
Before buying the ASUS ProArt Z890-CREATOR WIFI in Bangladesh, confirm that your processor uses the LGA1851 socket and is supported by the motherboard. Choose a compatible DDR5 memory kit, an adequately rated power supply, suitable CPU cooling, and an ATX-compatible PC case. If your workflow involves large media libraries, consider how many M.2 and SATA drives you need and review the shared-bandwidth limitation affecting the fifth M.2 slot.
Also consider whether your current network equipment supports 10Gb Ethernet or Wi-Fi 7; the motherboard cannot provide the full benefits of these technologies without compatible networking equipment. Compare the ASUS ProArt model with other Intel Z890 motherboards based on connectivity, expansion, storage requirements, and total workstation cost rather than chipset name alone.
It is designed for professional creator PCs and high-performance workstations used for video editing, 3D design, software development, and other demanding workloads.
The motherboard supports Intel Core Ultra Processors (Series 2) with the LGA1851 socket. Check ASUS's CPU support list before purchasing a processor.
It supports up to 256GB of DDR5 memory across four DIMM slots. Supported memory speeds depend on the processor, memory modules, and configuration.
You can install up to five M.2 storage devices, subject to supported drive formats and interfaces. The fifth M.2 slot shares bandwidth with the PCIe 4.0 x16 slot and disables that slot when in use.
Yes. It has two Thunderbolt 5 USB Type-C ports and one Thunderbolt 4 USB Type-C port. Compatible devices and the appropriate cables are required to use their supported features.
Yes. It includes Wi-Fi 7 and Bluetooth 5.4. Actual wireless performance and available features depend on compatible networking equipment, operating-system support, and regional regulations.
The price can vary with stock availability, seller pricing, and warranty terms. Check the current listing at Potaka IT for the latest price and availability in Bangladesh.
The ASUS ProArt Z890-CREATOR WIFI is a strong option for buyers who need professional connectivity, extensive SSD expansion, high-speed networking, and support for modern Intel Core Ultra processors. Its combination of Thunderbolt 5, DDR5 memory, PCIe 5.0, and Wi-Fi 7 makes it suitable for building a workstation around demanding creative and productivity requirements. Review the specifications, compatibility requirements, and warranty details before choosing this motherboard for your next PC build.
Visit Potaka IT to check the ASUS ProArt Z890-CREATOR WIFI motherboard price in Bangladesh and explore availability for your workstation build.
The latest price of ASUS ProArt Z890-CREATOR WIFI LGA1851 Motherboard in Bangladesh is 81,950৳. You can buy the ASUS ProArt Z890-CREATOR WIFI LGA1851 Motherboard at best price from our website or visit any of our showrooms.
