| Basic Information | ||
| Supported CPU | AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors | |
| Chipset | AMD B850 | |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm) |
|
| Audio | Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback* Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers - Audio cover - Unique de-pop circuit * Due to limitations in HDA bandwidth, 32-bit/192 kHz is not supported for 7.1 Surround Sound audio. |
|
| Expansion Slots | ||
| PCI | AMD Ryzen 9000 & 7000 Series Desktop Processors* 1 x PCIe 5.0 x16 slot (supports x16 mode) AMD Ryzen 8000 Series Desktop Processors 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)** AMD B850 Chipset 1 x PCIe 4.0 x16 slot (supports x4 mode)*** 1 x PCIe 4.0 x1 slot |
|
| M.2 Socket | 3 x M.2 | |
| Memory | ||
| Type | DDR5 | |
| Slots | 4 x DIMM | |
| Supported Memory | Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM* Dual-channel memory architecture Supports AMD Extended Profiles for Overclocking (EXPO™) ASUS Enhanced Memory Profile (AEMP) * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1 x DisplayPort* 1 x HDMI™ port** - Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. * Supports max. 8K@30Hz as specified in DisplayPort 1.4 ** Supports 4K@60Hz as specified in HDMI 2.1 *** VGA resolution support depends on processors' or graphic cards' resolution. |
|
| Connector & Ports | ||
| HDMI | 1x HDMI 2.1 | |
| Internal I/O Ports | Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 2 x 8-pin +12V CPU Power connectors Storage Related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 10Gbps connector (supports USB Type-C® ) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable RGB Gen 2 headers 1 x Clear CMOS header 1 x Chassis Intrusion header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x 10-1 pin Front Panel System header 1 x Thunderbolt™ (USB4®) header BTF Related 1 x 12V-2X6 Auxiliary Power connector 1 x Graphics Card High-Power slot |
|
| Display Port (s) | 1x DisplayPort 1.4 | |
| USB (s) | Rear USB (Total 10 ports) 1 x USB 20Gbps port (1 x USB Type-C®) 3 x USB 10Gbps ports (3 x Type-A) 4 x USB 5Gbps ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 7 ports) 1 x USB 10Gbps connector (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports * USB Type-C® power delivery output: max. 5V/3A. |
|
| LAN Port (s) | 1 x Realtek 2.5Gb Ethernet TUF LANGuard |
|
| Supported Storage | Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen™ 9000 & 7000 Series Desktop Processors M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) AMD Ryzen™ 8000 Series Desktop Processors M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4/x2 mode)* AMD B850 Chipset M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)** 4 x SATA 6Gb/s ports * Specifications vary by CPU types. ** The M.2_3 slot shares bandwidth with the PCIEX16(G4) slot. When the PCIEX16(G4) slot is operating, the M.2_3 slot will be disabled. |
|
| Audio | 5 x Audio jacks | |
| Wireless Communication module | Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band** Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate Bluetooth® v5.4*** * Wi-Fi features may vary depending on the operating system. For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E. For Windows 10, only Wi-Fi 6 is supported. ** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries |
|
| RAID | AMD RAIDXpert2 Technology Ryzen™ 9000 Series Processors: RAID 0/1/5/10 Ryzen™ 8000 Series Processors: RAID 0/1 Ryzen™ 7000 Series Processors: RAID 0/1/10 |
|
| Others | ||
| Special Features | ASUS TUF PROTECTION - DIGI+ VRM (- Digital power design with DrMOS) - ESD Guards - TUF LANGuard - Overvoltage protection - SafeSlot - Stainless-steel back I/O ASUS Q-Design - M.2 Q-Latch - M.2 Q-Release - PCIe Slot Q-Release Slim (with PCIe SafeSlot) - Q-Antenna - Q-Dashboard - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - ProCool - Pre-mounted I/O shield - SafeDIMM Aura Sync - Addressable RGB Gen 2 headers |
|
| Bundled Software | ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 4 ASUS AI Advisor ASUS DriverHub ASUS GlideX TurboV Core TUF GAMING CPU-Z DTS Audio Processing Adobe Creative Cloud (Free Trial) Norton 360 for Gamers (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years Warranty | |
The Asus TUF GAMING B850-BTF WIFI W ATX Motherboard brings next-gen performance, ultra-durable components, and sleek cable management to serious gamers and PC builders. Designed with AMD Ryzen 9000, 8000, and 7000 series processors in mind, this BTF (Back-To-the-Future) motherboard combines high-speed connectivity, Wi-Fi 7 support, and stunning DDR5 memory performance in one robust ATX form factor. If you're building a powerful gaming or creator rig, this motherboard gives you everything you need—and then some.
At the heart of the TUF GAMING B850-BTF is AMD’s B850 chipset, fully compatible with the latest Ryzen 9000, 8000, and 7000 series desktop processors using the AM5 socket. This ensures you’re ready for today’s workloads and tomorrow’s innovations without upgrading your entire platform.
Supporting up to 256GB of DDR5 RAM, this board offers lightning-fast memory speeds of up to 8000+MT/s (OC). Dual-channel architecture, AMD EXPO, and ASUS AEMP profiles allow seamless overclocking and tuning, making multitasking and high-performance gaming smoother than ever.
Equipped with a PCIe 5.0 x16 slot, the motherboard ensures future-proof graphics support for the latest GPUs. With multiple PCIe 4.0 x16 and x1 slots, and three M.2 slots (including PCIe 5.0 M.2 support), your build will have the speed and bandwidth for intensive gaming, content creation, and fast storage.
Stay ahead of the curve with built-in Wi-Fi 7, offering ultra-fast wireless speeds up to 2.9Gbps, tri-band support (2.4GHz/5GHz/6GHz), and lower latency. Whether you’re streaming, gaming online, or downloading large files, you’ll experience fewer drops and faster transfer rates. Plus, Bluetooth 5.4 ensures smooth connectivity with peripherals and accessories.
Built with ASUS TUF Protection, the B850-BTF motherboard offers military-grade durability, including DIGI+ VRM, ESD Guards, TUF LANGuard, and Stainless-Steel I/O. This rugged design ensures stability and safety even under high workloads or overclocking conditions.
Enjoy immersive audio with Realtek ALC1220P 7.1 surround sound, powered by premium capacitors, internal amplifiers, and isolated PCB layers. The result? Rich, clear sound whether you’re gaming, watching movies, or editing video. With a total of 17 USB ports (10 rear + 7 front), including USB Type-C® 20Gbps, this board keeps you connected to all your peripherals and high-speed storage devices. Video output includes DisplayPort 1.4 (8K@30Hz) and HDMI 2.1 (4K@60Hz)—ideal for high-resolution monitors and content creators.
At Potaka IT, we offer only 100% authentic and officially distributed Asus motherboards in Bangladesh, backed by local warranties and expert support. When you buy the Asus TUF GAMING B850-BTF WIFI W from us, you're not just getting a product—you’re investing in long-term performance, trusted customer service, and fast nationwide delivery. Whether you're upgrading your gaming rig or building a workstation for creative workloads, Potaka IT gives you access to the best motherboard deals in Bangladesh, with genuine components and secure checkout options. With our expert guidance and support, you’ll make the right choice every time.
The latest price of Asus TUF GAMING B850-BTF WIFI W Motherboard in Bangladesh is 41,500৳. You can buy the Asus TUF GAMING B850-BTF WIFI W Motherboard at best price from our website or visit any of our showrooms.
