| Basic Information | ||
| Supported CPU | Supports Intel Core Ultra Processors (Series 2) | |
| Chipset | INTEL Z890 | |
| Form Factor | ATX (243.84mmx304.8mm) | |
| Audio | Realtek ALC1220P Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
|
| Expansion Slots | ||
| PCI | 3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
|
| M.2 Socket | 4x M.2 | |
| Memory | ||
| Slots | DDR5 | |
| Supported Memory | Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 9200+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 4800+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports Intel® POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM |
|
| Maximum Memory | 256GB | |
| Graphics | ||
| Graphics | 1x HDMI™ Support HDMI™ 2.1 with FRL, maximum resolution of 4K 120Hz* 2x Type-C DisplayPort Thunderbolt™ 4 ports, supporting DisplayPort 1.4 over USB Type-C®, with a maximum resolution of 4K 120Hz / 8K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Internal I/O Ports | 1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 6x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
|
| Display Port (s) | 2x Type-C DisplayPort Thunderbolt 4 ports, supporting DisplayPort 1.4 |
|
| USB (s) | 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) *USB 20Gbps Type-C (Front) support USB PD 27W fast charging for JUSBC1 |
|
| LAN Port (s) | Intel Killer E5000 5Gbps LAN | |
| Supported Storage | 4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
|
| Audio | 1x Front Audio (JAUD) | |
| Wireless Communication module | Intel® Killer™ BE1750x Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4**, MLO, 4KQAM |
|
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Year warranty | |
The MSI MAG Z890 TOMAHAWK WIFI LGA 1851 ATX Motherboard is a powerful and feature-rich motherboard designed for gamers, content creators, and PC enthusiasts who want cutting-edge performance and reliable stability. Powered by the Intel Z890 chipset and built for Intel Core Ultra Series 2 processors, this motherboard combines PCIe 5.0 support, ultra-fast DDR5 memory, Wi-Fi 7 connectivity, and advanced cooling solutions to create a future-ready gaming and productivity platform.
The MSI MAG Z890 TOMAHAWK WIFI supports Intel Core Ultra Series 2 processors on the latest LGA 1851 socket, delivering exceptional processing power for gaming, streaming, multitasking, and professional workloads. The advanced Intel Z890 chipset ensures efficient power delivery, improved stability, and smooth system performance for high-end PC builds.
Designed for next-generation performance, this motherboard supports up to 256GB of DDR5 memory with overclocking speeds reaching 9200+ MT/s. It supports Intel XMP 3.0, dual-channel architecture, and memory overclocking for faster responsiveness and smoother multitasking. Whether you are gaming competitively or editing large projects, the MSI MAG Z890 TOMAHAWK WIFI ensures ultra-fast memory performance.
The motherboard features PCIe 5.0 x16 support for the latest graphics cards and high-performance expansion devices. It also includes four M.2 slots with PCIe 5.0 and PCIe 4.0 support, enabling ultra-fast SSD performance for rapid boot times, faster file transfers, and improved gaming load speeds. RAID support for both SATA and NVMe storage provides enhanced flexibility and data management options.
Equipped with Intel Killer BE1750x Wi-Fi 7 and Bluetooth 5.4, this motherboard delivers lightning-fast wireless networking with reduced latency and enhanced stability. The Intel Killer E5000 5Gbps LAN port ensures high-speed wired connectivity, making it perfect for competitive gaming, streaming, and heavy online workloads.
The MSI MAG Z890 TOMAHAWK WIFI includes dual Thunderbolt 4 Type-C DisplayPort connections that support ultra-high-resolution displays up to 8K at 60Hz. Multiple USB 10Gbps and 20Gbps ports provide ultra-fast connectivity for external drives, gaming peripherals, and professional accessories. The front USB Type-C port also supports 27W fast charging for compatible devices.
Powered by the Realtek ALC1220P codec, this motherboard delivers high-definition 7.1-channel audio with crystal-clear sound quality for gaming, music, and entertainment. Support for S/PDIF output further enhances audio performance for immersive gaming and multimedia experiences.
The MSI MAG Z890 TOMAHAWK WIFI is equipped with multiple fan headers, pump support, and smart cooling controls to maintain stable temperatures during heavy workloads. Its durable ATX design, RGB lighting support, and EZ connectivity features make PC building and customization easier for both beginners and enthusiasts.
With support for PCIe 5.0, DDR5 memory, Wi-Fi 7, Thunderbolt 4, and advanced storage solutions, the MSI MAG Z890 TOMAHAWK WIFI motherboard is built to handle modern gaming, streaming, video editing, and professional multitasking. It delivers the performance and reliability needed for powerful next-generation PC systems.
When you purchase the MSI MAG Z890 TOMAHAWK WIFI LGA 1851 ATX Motherboard from Potaka IT, you are guaranteed a 100% genuine MSI product at a competitive price. Potaka IT offers trusted customer support, authentic PC components, and reliable after-sales service to ensure a secure and hassle-free shopping experience for every customer.
The latest price of MSI MAG Z890 TOMAHAWK WIFI ATX Motherboard in Bangladesh is 49,500৳. You can buy the MSI MAG Z890 TOMAHAWK WIFI ATX Motherboard at best price from our website or visit any of our showrooms.
